ARTISOFT, INC.
AE-2 MC
|
NIC Type |
Ethernet |
|
Transfer Rate |
10Mbps |
|
Data Bus |
16-bit MCA |
|
Topology |
Linear Bus |
|
Wiring Type |
RG-58A/U 50ohm coaxial AUI transceiver via DB-15 port |
|
Boot ROM |
Available |
|
CABLE TYPE | ||
|
Type |
W1 - W6 | |
| » |
RG-58A/U 50ohm coaxial |
Pins 1 & 2 Closed |
|
AUI transceiver via DB-15 port |
Pins 2 & 3 Closed | |
|
NETWORK SEGMENT LENGTH | ||
|
Length |
W7 | |
| » |
185 Meters |
Pins 2 & 3 Closed |
|
300 Meters |
Pins 1 & 2 Closed | |
|
Note:If 300 meters is enabled, the network must consist of only one single segment. There can be no hubs or
| ||
