EAGLE TECHNOLOGY
RX-NET II
|
NIC Type |
ARCnet |
|
Transfer Rate |
2.5Mbps |
|
Data Bus |
8-bit ISA |
|
Topology |
Star |
|
Wiring Type |
RG-62A/U 93ohm coaxial |
|
Boot ROM |
Available |
|
NODE ADDRESS |
||||||||
|
Node |
SW3/1 |
SW3/2 |
SW3/3 |
SW3/4 |
SW3/5 |
SW3/6 |
SW3/7 |
SW3/8 |
|
0 |
- |
- |
- |
- |
- |
- |
- |
- |
|
1 |
Off |
On |
On |
On |
On |
On |
On |
On |
|
2 |
On |
Off |
On |
On |
On |
On |
On |
On |
|
3 |
Off |
Off |
On |
On |
On |
On |
On |
On |
|
4 |
On |
On |
Off |
On |
On |
On |
On |
On |
|
251 |
Off |
Off |
On |
Off |
Off |
Off |
Off |
Off |
|
252 |
On |
On |
Off |
Off |
Off |
Off |
Off |
Off |
|
253 |
Off |
On |
Off |
Off |
Off |
Off |
Off |
Off |
|
254 |
On |
Off |
Off |
Off |
Off |
Off |
Off |
Off |
|
255 |
Off |
Off |
Off |
Off |
Off |
Off |
Off |
Off |
|
Note:Node address 0 is used for messaging between nodes and must not be used. A total of 255 node address settings are available. The switches are a binary representation of the decimal node addresses. Switch 1 is the Least Significant Bit and switch 8 is the Most Significant Bit. The switches have the following decimal values: switch 1=1, 2=2, 3=4, 4=8, 5=16, 6=32, 7=64, 8=128. Turn off the switches and add the values of the off switches to obtain the correct node address. (On=0, Off=1) |
||||||||
|
INTERRUPT REQUEST |
|||||
|
IRQ |
JP1 |
JP2 |
JP3 |
JP4 |
JP5 |
|
2 |
Closed |
Open |
Open |
Open |
Open |
|
3 |
Open |
Closed |
Open |
Open |
Open |
|
4 |
Open |
Open |
Closed |
Open |
Open |
|
5 |
Open |
Open |
Open |
Closed |
Open |
|
7 |
Open |
Open |
Open |
Open |
Closed |
|
I/O BASE ADDRESS |
||||||
|
Address |
SW2/1 |
SW2/2 |
SW2/3 |
SW2/4 |
SW2/5 |
SW2/6 |
|
200h |
Off |
On |
On |
On |
On |
On |
|
250h |
Off |
On |
On |
Off |
On |
Off |
|
2A0h |
Off |
On |
Off |
On |
Off |
On |
|
2E0h |
Off |
On |
Off |
Off |
Off |
On |
|
2F0h |
Off |
On |
Off |
Off |
Off |
Off |
|
300h |
Off |
Off |
On |
On |
On |
On |
|
350h |
Off |
Off |
On |
Off |
On |
Off |
|
3E0h |
Off |
Off |
Off |
Off |
Off |
Off |
|
BUFFER ADDRESS |
||||||
|
Address |
SW1/1 |
SW1/2 |
SW1/3 |
SW1/4 |
SW1/5 |
SW1/6 |
|
C0000h |
Off |
Off |
On |
On |
On |
On |
|
C4000h |
Off |
Off |
On |
On |
On |
Off |
|
C8000h |
Off |
Off |
On |
On |
On |
On |
|
CC000h |
Off |
Off |
On |
On |
Off |
Off |
|
D0000h |
Off |
Off |
On |
Off |
On |
On |
|
D4000h |
Off |
Off |
On |
Off |
On |
On |
|
D8000h |
Off |
Off |
On |
Off |
Off |
On |
|
DC000h |
Off |
Off |
On |
Off |
Off |
Off |
|
E0000h |
Off |
Off |
Off |
On |
On |
On |
|
FACTORY CONFIGURED SETTINGS |
|
|
Jumper/Switch |
Setting |
|
JP6 |
N/A |
|
SW1/7 |
On |
|
SW1/8 |
On |
