SONY CORPORATION
CDU-541
|
Device Type |
CD-ROM |
|
Interface |
SCSI |
|
Spin Rate |
2x |
|
Formats Supported |
Audio combined, CD-Audio, CD-ROM (mode 1 & 2), High Sierra, ISO-9660, Red & Yellow Book |
|
View |
Bottom |
|
CONNECTIONS | |
|
Function |
Label |
|
Audio line out |
CN1 |
|
USER CONFIGURABLE SETTINGS | |||
|
Setting |
Label |
Position | |
| » |
Parity enabled |
JP1/1 |
Closed |
|
Parity disabled |
JP1/1 |
Open | |
|
DRIVE SELECT ID | ||||
|
Drive ID |
JP1/2 |
JP1/3 |
JP1/4 | |
| » |
0 |
Open |
Open |
Open |
|
1 |
Closed |
Open |
Open | |
|
2 |
Open |
Closed |
Open | |
|
3 |
Closed |
Closed |
Open | |
|
4 |
Open |
Open |
Closed | |
|
5 |
Closed |
Open |
Closed | |
|
6 |
Closed |
Open |
Open | |
|
7 |
Closed |
Closed |
Closed | |
