Card Type	Video card
Video Chip Set	Chips and Technology
Maximum Video Memory	1MB
Data Bus	16-bit ISA
Video Types Supported	VGA
Highest Resolution Supported	1024 x 768

CONNECTIONS
Function	Label
15-pin video analog video port	CN2

VIDEO MEMORY CONFIGURATION
Size	Bank 0	Bank 1
512KB	512KB	None
1MB	512KB	512KB
Note: The size of the memory chips is unidentified.
