Card Type	Video card
Video Chip Set	Number 9 Imagine 128
Highest Resolution Supported	1600 x 1280
Maximum Video Memory	4MB VRAM & DRAM
Data Bus	32-bit PCI
Video Types Supported	XVGA

CONNECTIONS
Function	Label
15-pin analog video port	CN1

DRAM CONFIGURATION

Note: The exact DRAM chip size is unidentified.

MISCELLANEOUS TECHNICAL NOTE

Note: Number Nine also makes the Imagine 128 board with 8MB of VRAM.
