Card Type	Video card
Video Chip Set	Intel 440LX/BX
Maximum Video Memory	8MB SDRAM/SGRAM
Video Types Supported	VGA
Highest Resolution Supported	1600 x 1200
Data Bus	AGP

CONNECTIONS
Function	Label	Function	Label
15-pin analog video port	CN1	Memory upgrade socket	CN3

MISCELLANEOUS TECHNICAL NOTES

Available with ATX or NLX bracket. Also available with 4MB SGRAM.
